The American house-carpenter; a treatise on the art of building, and the strength of materials (1873)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 408
Fig. 869. 518.—To find the shadow thrown on a column by a squareabacus. From a and b, (Fig. 358,) draw the rays, a c and b e,and from c, erect the perpendicular, c e ; tangical to the curve atd, draw the ray, d /, and from h, corresponding to / in the plan,draw the ray, ho; take any point between a…
Carpentry · Architecture
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
