The American house-carpenter; a treatise upon architecture, cornices and mouldings, framing, doors, windows, and stairs. Together with the most important principles of practical geometry (1852)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 255
e top over a corresponding one at the base.The ordinates, n x and r s, in those figures, correspond to n xand r s in Fig. 286 and 287. In Fig. 288, the top, e a, forms a right angle with the face, dc ; all that is necessary, therefore, in this figure, is to find a linecorresponding to h x in the… … Fit: 288. r to e c on the top. This elucidates Fig. 276 ; at which the lines,h 9 and i 8, correspond lo h 9 and i 8 in this figure.
Carpentry · Architecture
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
