The American house-carpenter; a treatise upon architecture, cornices and mouldings, framing, doors, windows, and stairs. Together with the most important principles of practical geometry (1852)

Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 96

An illustration from The American house-carpenter; a treatise upon architecture, cornices and mouldings, framing, doors, windows, and stairs. Together with the most important principles of practical geometry, 1852, leaf 96 — Fig. 111. ARCHITECTURE. 79 three diameters, arceostyle, or columns thin-set. In all the orders,when there are four columns in one row, the arrangement iscalled, tetrastyle ; when there are six in a row, hexastyle ; andwhen eight, octastyle. 194.—-The Ionic order is appropriate for churches,… … AMERICAN HOUSE-CARPENTER.

Carpentry · Architecture

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
