The American house-carpenter; a treatise on the art of building, and the strength of materials (1867)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 327
lay thefirst courses of brick in the form of an arch. This brick archof itself is quite sufficient to sustain the compressive strain,and, were there proper resistance to the horizontal thrust pro-vided, the brick arch would entirely supersede the necessityfor the girder. Indeed, the instances are… … Fig. 2T9. FEAMTNG. 316 brick arcli, in tliis case, being built upon a wooden centre,which was afterwards removed. The diameter of the rod required for an arch of this kind isequal to ^=^mh ^-^ where w equals the weight in pounds equally diffused over thearch; s, the length of the rod, clear of the…
Carpentry · Architecture
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
