e other at g ; join g and e ; upon / and g, with d h and a b for radius, describe arcs intersecting at h ; join g and A, also h and /; then Fig. 66 will every way equal Fig. 65. So, right-lined figures of any number of sides may be copied,oy first dividing them into triangles, and then proceeding… … 101.— To make a parallelogram equal to a given triangle. Let a b c, {Fig. 67,) be the given triangle. From a, draw a d, at right angles to be; bisect a d in e ; through e, draw/^, parallel to 6 c ; from 6 and c, draw b f and c g, parallel to d e ; then bfgc will be a parallelogram containing a…
