Fig. 29. 73.— To let fall a perpendicular. Let a, [Fig. 29,) be thepoint, above the line, h c, from which the perpendicular is re-quired to fall. Upon a, with any radius greater than a d, de-scribe an arc, cutting 6 c at e and/; upon the points, e and/,with any radius greater than e d, describe… … Fig. 30. 74.— To erect a perpendicular at the end of a line. Let a,(Fig. 30,) at the end of the line, c a, be the point at which theperpendicular is to be erected. Take any point, as 6, above the 3 18 AMERICAN HOUSE-CARPENTER. line, c a, and with the radius, b a, describe the arc, d a e, through d…
