Fig. 42. S3.— The same, without making use of the centre of thecircle. Let a, {Fig. 42,) be the given point. From a, set oiFany distance to 6, and the same from b to c; join a and c ;upon a, with a b for radius, describe the arc, d b e ; make d bequal to be; through a and d, draw a line ; this will… … a line to the centre d ; bisect a d at e ; ^ipon e, with the radius, e a, describe the arc, afd;fis the point of contact required. If/ and d were joined, the line would form right angles withthe tangent, b c. (See A/^t. 156.) b
