91.—About a given circle, to describe an equi-lateral tri-angle. Let a d b c, {Fig. 51,) be the given circle. Draw thediameter, c d ; upon d, with the radius of the given circle, de-scribe the arc, a e b ; join a and b ; drsiW f g, at right angles tod c ; make/c and c g, each equal to a b ; from/,… … g P 92.— To find a right line nearly equal to the circumferenceof a circle. Let ah c d^ [Fig. 52,) be the given circle. Drawthe diameter, a c ; on this erect a.n equi-lateral triangle, a e c,according to Art. 96 ; draw gf parallel to a c ; extend e c to/,also e ato g ; then ^/will be nearly the…
