American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions (1914)

Colvin, Fred H. (Fred Herbert), 1867-1965, Stanley, Frank A. (Frank Arthur), b. 1874 · New York : McGraw-Hill book company ; London : Hill · leaf 134

An illustration from American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions, 1914, leaf 134
5 P, 4^. io6 GEARING LAYING OUT SINGLE CURVE TOOTH A VERY simple method of laying out a standard tooth is shownin Fig. 5, and is known as the single curve method. Having calcu-lated the various proportions of the tooth by rules already given,draw the pitch, outside, working depth and clearance or…

Machine-shop practice

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
