American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions (1914)

Colvin, Fred H. (Fred Herbert), 1867-1965, Stanley, Frank A. (Frank Arthur), b. 1874 · New York : McGraw-Hill book company ; London : Hill · leaf 176

An illustration from American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions, 1914, leaf 176
the cutter and thesechips were rolled up in pieces much like the chips obtained from abroad planer tool, when taking a finishing cut. This cut was takenwith a feed of 11 inches per minute. Another similar cut, but i inchand 11 inches in section, was taken with a feed of ^s inches perminute. SHELL… … /32 6 Diam. - Side Mills When milling steel, a heavy flow of oil on a milHng cutter, forcedby means of an oil pump, is just as essential as the great volume ofoil which is used on automatic screw machine tools, which wouldnot hold up one-half hour if not so flushed. The life of a millingcutter…

Machine-shop practice
