American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions (1914)

Colvin, Fred H. (Fred Herbert), 1867-1965, Stanley, Frank A. (Frank Arthur), b. 1874 · New York : McGraw-Hill book company ; London : Hill · leaf 371

An illustration from American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions, 1914, leaf 371
-tance these disks are apart. These three dimensions accurately andpositively determine the taper represented by the straigh.-edgestouching the rolls. If a record is made of these three dimensionsthese conditions can be reproduced at any time, thus making it pos-sible to duplicate a taper piece… … Taper per Foot =%FIG. 2

Machine-shop practice
