American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions (1914)

Colvin, Fred H. (Fred Herbert), 1867-1965, Stanley, Frank A. (Frank Arthur), b. 1874 · New York : McGraw-Hill book company ; London : Hill · leaf 644

An illustration from American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions, 1914, leaf 644
Key Seater — Machinepulleys or gears. … 6i6 KEYWAY — LATHE PARTS Keyway -^ A groove, usually square or rectangular, in which the keyis driven or in which a feather slides. The groove in both theshaft and piece which is to be fastened to it, or guided on it, iscalled a keyway. Knurling — See Nurling. Land — Space between flutes or grooves…

Machine-shop practice

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
