ernating current of 500 volts. Or where current is notavailable to operate an electric motor, an engine-driven generator is employed. Tis a step-up transformer which transforms the current to 25,000 or 50,000 volts.This latter current charges a condenser c, or Ley den jars (a capacity equal to… … .-•t rt=l- ri=<i JVWVWA a brass disc between two small brass balls is employed, the latter being adjustable^the disc stationary. The balls are supported in a vertical position on corrugated pillarsof ebonite; t is a choking or impedance transformer with a ratio of transformationof unity, that…
