construct any number of tangential arcs of circles,— as a cinquefoil, for example, having a given diameter. Upon a given diameter A B, as a base, construct a regular pen-tagon. From each angle of the pentagon as a centre, and with aradius of half the base, describe the five arcs. If three foils are…
