that it shall con- verge to the vertex of the angle made by the given lines. Draw any line 1 2, between E and the vertex of the angle. Draw1 E, 2 E. Draw a second line 3 4 parallel to 1 2. From 2 and 4 Idraw lines parallel with 1 E and 2 E, respectively, meeting in F. .A line drawn through E F is…
