18 ESSENTIALS OF DRAFTING To construct a Regular Octagon (Fig. 40). — Given the square1-2-3-4. With the corners of the square as centers, and a radiusequal to one half the diagonal, draw arcs cutting the sides of thesquare. Join the points thus found, completing the requiredoctagon. An octagon may… … Fig.^2
