The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths." (1894)

Barker, A. F. (Aldred Farrer), b. 1868 · Manchester : Marsden · leaf 145

An illustration from The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths.", 1894, leaf 145
er, the astrakan type of structureis required this order of interweaving is not necessary or 132 perchance desirable, for, as shown in Figure 62, byfloating the pile thread before cutting, a longer length ofpile to curl is obtained. J Fig. 62. Procedure in Analysis.—i- in analysing any figures… … Fig. 60A. 3. By extracting weft picks and noticing the loopingthe proportion of picks to wires will be ascertained. 4. Having selected the design paper in accordancewith the relative number of pile and ground threads, and 133 picks and wires, indicate clearly upon this paper theground and pile…

Textile design · Weaving

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
