The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths." (1894)

Barker, A. F. (Aldred Farrer), b. 1868 · Manchester : Marsden · leaf 59

An illustration from The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths.", 1894, leaf 59
ft will besimilar. If a dot has been added, however, the curvatureof warp and weft will be very different. FANCY COMBINATIONS.Having discussed the means of arriving at the weavesof the simpler cloths, attention must now be turned tocombinations of the foregoing, such as in stripes, checks,etc.… … Fig. ig.may be taken from the surface by means of a piece-glass. Suppose they are respectively Designs I. and VI.,then there is usually no need to examine the exact way 47 in which they are combined in the cloth, which wouldonly be waste of time, for they may be equally well com-bined on design…

Textile design · Weaving
