jection of d atd by a ray of light from c; d1 is the high-est point in the curve. Take any horizon-tal line E F in the elevation and describefrom C on the plan an arc with a radius equal to one half this line; draw from C a ray intersecting E F at e, whichproject to e, and from e as a centre… … FIG. 320.
