tened on top and bot-tom, so that the boxes ofthe rod can never bind onthe pin at the extreme ofthe vibrations of the rod ;usually these pins areround. The pin is formedwith large squares at theends, by which it is fittedinto the jaws of the cross-head, where it is secured FIG. so?.by a steel pin…
