A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .. (1873)
[Scott, David] engineer. [from old catalog] · New York, D. Appleton and company · leaf 90
arriage slides, and which has itsaxes of vibration to adapt the cut-ter to the required depth of cogsat the apex of a cone correspond-ing with the bevel of the wheelto be cut, whether such axes befixed or adjustable to wheels ofdifferent sizes, that all the cutsmay be in the direction of theradii.… … 82 GEER-CUTTING MACHINE, BEVEL. be cut in the machine, that the axis of vibration of the guide-bar may be elevated or depressed tcadapt the machine to different bevels; and that the main driving shaft, which communicates motion tctlie operative parts of the machinery placed at the hinged end of the…
Gearing · Mills and mill-work · Odontograph
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
