FIG. 1112. SCALE : J * = 1 foot.FIG. 1113. In the large Washington sewer the man-hole is constructed on the side ofthe sewer; in the Brooklyn one the aperture of the man-hole comes within theexterior wall. In most sewers it is directly over them. Figs. 1112 and 1113 are section andplan of the…
