ected against rust by galvanizing orheavy coats of paint or by both. Fig. 1430shows a section of a galvanized cornice withbar-iron frames anchored to the wall and FlG 1430 roof and riveted to the cornice; the joints of the cornice should be both riveted and soldered. The pitch of the gutter…
