Appletons' cyclopædia of technical drawing : embracing the principles of construction as applied to practical design ... (1896)
Worthen, W. E. (William Ezra), 1819-1897 · New York : D. Appleton · leaf 640
FIG. 1510. Fui. 1511. … limb was made equal to that of the transept, sometimes even longer, but neverto exceed that of the nave. In the Greek cross all the limbs are equal. Inmost of the French Gothic churches the eastern end is made semicircular, ofteninclosed by three or more apsidal chapels, that is, semi-cylinders,…
