s, IF and IF, the latter revolving in the former. As will be seen from the engraving, the cone-pulley i?, receiving the first motion,drives the external mandrel IF. The toothed wheels Z, Z, Z, and Z form the usual lathe-gear-ing, and both the toothed wheels ZZ drive a shaft w, to the end of which… … 248 LATHE-CHUCKS. mandrel W and of the external mandrel may be produced. A disk E fixed to the internal mandrelmay be eccentrically adjusted on it; on this disk moves the face-plate on which the objects to beturned are fixed ; a driver M attached to the external mandrel causes this face-plate to…
