lined faces, acting on the upper inclined sidesof jaws D and E, will force these jaws together, and,as contact becomes closer, the projections F on the lat-ter will interlock. The square-shanked tool will then be held on two sides of the V of the jaw C, and on the other sides by the proximate parts… … 252 LATHE-CHUCKS. be carried back to their former places. If a tapered tool be inserted, the moving jaws D and E willassume an angular position, holding the shank tightly as before. Vintons Chuck is represented in Figs. 2G24 and 2025. The collar A which encircles the spindle 2627. 2628. 262J.
