Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)
D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 319
lettersof reference in the figures already referred to: A, A, cylinders ; B, main driving-axle: C, C, mainconnecting-rods; D, D, main crank-pins ; E, E, truck-wheels; F, back driving-axle; G, fire-box;H, H, H, frames ; 7,7, frame-clamps ; J, J, eccentrics ; K, K, rockers ; L, L, links; M,… … LOCOMOTIVE, DESCRIPTION OF PARTS OF THE. 305 dome; F F, cab or house; Z,back or trailing-wheel crank-pin ; A, pump air-chamber;B, B, main driving-wheels;C C C, supply-pipe; D,front platform; E, bumpertimber; F, F, back driv-ing-wheels; (?, coupling-pin;H, friction-plate; /, check-valve; K K,…
Mechanical engineering -- Dictionaries
