the bracketB, and to bore the holes for the bolts. The board, Fig. 3151, when reversed, should fit that in Fig.3152 at the lower part, and be of a shape to coincide with the dotted line. Its length must be enough.to extend to the centre, minus the radius of the spindle, as shown in Fig. 3151. It… … MOULDING. 455 when it is thought necessary. In striking up cores with a horizontal spindle, the working-edge ofthe board should be beveled; and it is hardly necessary to say that the same is applicable in this case.-PP, Fig. 3151, is a circular plate of cast iron, used to support the mould while…
