ingenious method adopted in the press represented in Fig. 3563 is shown in Fig. 3564. The upperend of the pitman A, carrying the slide F, is bored out and enlarged to receive an eccentric diskB. The lower end of the pitman is secured to the slide by the pin G. The disk B is bored out ofcentre…
