s of red- to yellow-hot brickwork, and then passes at an equally high temperature into4014. the furnace. Meanwhile, air regulated by the valve K is drawn through the furnaee-chimney into the reversing valve C (Fig.4014), which, being set similarly to C,guides the air through the flue 0 into… … gas is not carefully regulated, to melt down the roof of the furnace. The flame is thrown down bythe roof upon the bath of metal in the hearth ; thence it passes down the ports B S (Fig. 4015) intothe two regenerators J/Ar(Fig. 4013), which absorb its heat, and thence it escapes through the…
