ts Fig. 40. Fig. 41. ent methods to obtain this result. In figs. 37, 38, the joint is brought to abearing by a key driven in tight. Fig. 39 represents a scarf suited for abeam supported at this joint by a post, and where there is tensile strain,the timber sh(3>uld be joint-bolted or anchored.…
