int is a fine needleheld in a pair of forceps (fig. 53). It is used to markthe intersection of lines, or to set off divisions fromihe ])h)tting scale and protractor. This point mayalso ho used to prick through a drawing upon an R Fit;. 52. Ik. M. DRAWING INSTRUMENTS. 15 intended copy, or, the… … Fig. 54. the drawing-board so that the ink will follow the pen, which prevents blotsor the accnmnlation of too ninch ink at any one point. The dotting point (fig. 55) resembles a drawing pen, except that the23oints are not so sharp. On the back blade, as seen in the engraving, is apivot, on which…
