Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor (1866)
Worthen, William Ezra, 1819-1897, [from old catalog] ed, Appleton, firm, publishers, New York. (1866. D. Appleton & co.) [from old catalog] · New York, D. Appleton and company · leaf 407
271 rLATE LIX„ … ARCHITECTUEAL DRAWING. 271 lions instead of diverging in flowing or curvilinear lines, are carried upstraight tlirongli the head of the windows; smaller niullions spring fromthe head of the principal lights, and thus the upper portion of the windowis filled with panel-like compartments. The…
