Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor (1866)

Worthen, William Ezra, 1819-1897, [from old catalog] ed, Appleton, firm, publishers, New York. (1866. D. Appleton & co.) [from old catalog] · New York, D. Appleton and company · leaf 630

An illustration from Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor, 1866, leaf 630
PLATE CV. 402 … PERSPECTIVE DRAWING. 403 block aud upon the groimd plane, supposing the light to come into thepicture from the upper left-hand corner and at an angle of 45°. Since theangle of light is the diagonal of a cube, construct another cube similar toA, and adjacent to the face d c g ; draw the diagonal 11^…

Mechanical drawing · Architectural drawing · Projection · Perspective
