Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 279
shafts making 100 revolutions per minute, in which thetransverse strain, if any, need not be considered ; if of Diameterin inches. Wrought-iron. Steel. Diameterin inches. Wrought-iron. Steel. ! Diameterin inches. ! Wrought-iron. Steel. 1- 2-0 3 2 4-5 182- 291- 7-5 843- 1350- 1-5 6-7 10-7 5- 250-… … Horse-power.Fig. 561. Fig. 562 represents a line of shafting. A is an npright shaft; a a, bevel-gears ; 11, bearings for the shafts; c, coupling or connection of the severalpieces of shafting. These shafts are of wronght-iron or steel, of nniform sec-tion. As the power is distributed froni this…
Mechanical drawing
