Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 366
omo-tive engine, of cast-iron, with very long bolts, and a very rigid construction.The strap forms a cup-section over the projecting ring on the eccentric, andretains the oil at the bottom for more efficient lubrication and prevents drip. Figs. 783, 784, and 785 is another cast-iron eccentric… … Fig. 783. 350 MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS.
Mechanical drawing
