rflow at the end of thestroke. The great desideratumofr water - valves is that thereshould be little lift, but amplewater-way. Fig. 853 is a section of Fields pump-valves, an English design for high-waterservice, as fire-pumps, of which the flaps are rubber disks. For lower pressures,as for the… … Fig. 853.
