Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 406
esist collapse. Junction of more than Two Plates, shotvn in Plants and Sections (Figs. 906,907, and 908).—These become necessary when cross-joints intersect longitudi-nal ones. At these joints one or more of the plates are thinned or drawn outby forging. MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS.… … Fig. 906.
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
