Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 88
Fig. 17. Then the resistance to tearing along the outer row ofrivets is (2p—cl)tT 64 MACHINE DESIGN. As there are five rivets to compress in this strip thebearing resistance is 6dtC As there is one rivet in single shear and four indouble shear the resistance to shearing is 1 + (4 X 1.85) 1 ^d2S =…
Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
