Fig. 980. In most stationary engines the fly-wheel is a pulley or band-wheel or geardriving the machinery, but often the fly-wheel is independent. Fig. 980 is theelevation and section of a fl3^-wheel built by the Southwark Foundry. Theconstruction will be understood from the drawings, but the… … MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS. 411 connecting the segments, shown on a larger scale (Fig. 981), do not project,but are countersunk in the sides of the rim. The cast-iron fly-wheel of a steam engine 36 X T2, built for the Amos-keag Manufacturing Company in 1883, 30 feet diameter, 110…
