Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 116
Figs. 89 and 90.—Two views of the Thornycroft Spring Drive Wheel. A is the felloe ofthe wheel carrying the iron tire. B is the revolving axle, which is independent of thewheel except for the springs secured to it by the bolts, C. D is the angle piece atthe felloe carrying the lug to engage the…
Automobiles
