Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 472
ENGINEERING DRAWING. 455 Fig. 1071 is a drawing, in outline, of the hollow quoin of the lock-gate, ona scale of -^ full size (Chemung Canal). ^ V -»r- … FlG. 1070. Scale : ro = 1 foot. Fig. 1072 is a plan and elevation of pintal for heel-post of lock, with a sec-tion of the bottom of the post. The pintal is imbedded in bottom timber orstone, as the case may be.
Mechanical drawing
