Medieval architecture, its origins and development, with lists of monuments and bibliographies (1909)
Porter, Arthur Kingsley, 1883-1933 · New York, The Baker and Taylor Company · leaf 78
ample, which is assigned by M. Lefevi-e-Pontalis to the veryfirst years of the XII century, is also constructed on a plannearly square and evidently replaces an older groin vault, sincethe diagonals rest on corbels. The surface is not domed, butthe ridges are perfectly horizontal, and there are no… … III. 158. — Rib Vault at Rhuis. (Redrawn from Lefevre-Pontalis) 1 B j 3 ^: 1 r = rx _i —1 pJ —- — r 1 1 III. 159. — Rib Vault at Viffort. (Redrawn fromLefevre-Pontalis) EARLY RIB VAULTS on a plan approximately square. Since the arches of this vaultare all round, the crown is much domed. Wall ribs…
Architecture, Medieval
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
