Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 628
Fig. 1488, in a measure on the court, with a ventilating passage from the rear beneaththe fire-escape grating. Kitchens, in the figure, are attached to the suites;the laundries are in the upper story. Many flats are without kitchens or laun-dries, and meals are furnished either from without or from… … Sidewalk. ^ Fig. 1489. Fig. 1490. 612 ARCHITECTURAL CONSTRUCTION. torn, with ample and separate suites. It would seem that hoarding-housesmight be built on such plans—less extensive in their arrangements and adaptedto small families of moderate means ; but boarding-houses are almost…
Mechanical drawing
