Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 668
ththe basin, with usuallysmall drawers for towelsat each side of the closet.It is cleaner and neaterto support the slabs and basins by a metal frame and posts or brackets, with the traps and pipes ex-posed. A later form of wash-basin is an oval (largest size 19 X 15, outsidemeasure), which admits… … Fig. 1550. 652 ARCHITECTURAL CONSTRUCTION. not be readily cleaned. Fig. 1551 is a plan, and Fig. 1552 a section, of a cast-iron bath-tub porcelain-lined; there are cocks for hot and cold water; for thedischarge there is a standard waste, which can be taken out entirely, but thereis often a common…
Mechanical drawing
