Mechanics of the household; a course of study devoted to domestic machinery and household mechanical appliances (1918)
Keene, E. S. (Edward Spencer), b. 1864 · New York, McGraw-Hill book company, inc.; · leaf 112
9. Fig. 89a. Fig. 89.—Overflow attachment for bath tubs, lavatories, etc.Fig. 89a.—Drain attachment for bath tubs, avatories, etc., showing lock-nut and union connection. The drain-pipe connection is shown in Fig. 89a. The plug Dand the flange A show inside the tub. The flange is madewater-tight by… … Fig. 90.—Old style marble finishedlavatory.
Heating · Lighting · Plumbing
