One of this, Figs. 424 and 425, for two high-pressure engines, built by T. F. Secor and Co., in usefor a screw propeller boat, with 20-inch cylinders, and 2 feet stroke. 8 cubic feet in cylinders, whichgives 68 to 1. Uses anthracite, with blowers. Fire surface in thin boiler. Furnace 59-103 Main… … Two of this, Figs. 426 and 427, in use on steamboat John Mason, built by T. F. Secor and Co.,has^one engine of 25f in. cylinder, with 6 ft. stroke. Estimated weight of each, 8834 lbs. Estimated firesunace, 347 square ft. 21 cubic ft. in cylinder, which gives 33 to 1. Uses anthracite, without…
