se Section, BOILERS. 145 Figs. 483, 484, and 485, are different views of the boilers of the steamer Forth, belonging tothe English Mail Steam-Packet Company. These boilers are well ■worthy of the attention of theengineer, as they have approved themselves more economical than any of the other… … Scale.—l-llth inch = 1 foot.Longitudinal Sections. Scale.—1-lltli inch = 1 foot.Transverse Section. Front View. 485. c^: CZL Scale.—l-llth inch = 1 foot. ^ 486.
