rcumstances, be wound upand lowered, for which purpose the nuts are winged. The screw-bolts are at their ends provided withhooks rr, Figs. 480 and 481, which take hold of two side-laths b b, Fig. 481, of the cylindrical frame ofthe sieve. On the other hand the brush-cylinder, whose shaft//rests on… … 164 BOND. nected with it by o. This spout is shaken by a nave v, fixed at the shaft//, which beats during therotation against a tuck at the bottom of the shoe. By the slide at w, the quantity of ground grain inthe shoe can be increased or decreased. The slide x, which in Fig. 477 is closed, is shut…
