Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)
Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 182
lling a hole when the brace is moved round in the usualdirection, which agrees with the path of a left-hand screw. The cutting motion produces no change inthe length of the instrument, and the screw being held at rest for a moment during the revolution, setsin the cut; but towards the last, the… … CD plilEEB^ w 553. ..£] The lever-drill, Fig. 550, differs from the latter figure in many respects; it is much stronger, ana ap-plicable to larger holes ; the drill-socket is sufficiently long to be cut into the left-hand screw, and thepiece serving as the screwed nut, is a loop terminating in the…
Mechanical engineering
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
